Ürün ayrıntıları:
Menşe yeri: Çin
Marka adı: Kuoman
Model numarası: KM500-600W Güneş Paneli
Ödeme & teslimat koşulları:
Min sipariş miktarı: 1
Fiyat: USD1-100/pcs
Ambalaj bilgileri: standart uluslararası karton ambalaj
Teslim süresi: genel iki hafta, tam miktara göre daha fazla miktar
Ödeme koşulları: L/K, L/K
Yetenek temini: 2000BTU
İletişim

Solar module system module power panels for energy system

Açıklama
İsim: Güneş Modülü Sistemi Panel Verimliliği: % 22
Panel boyutları: 1903x1134x35mm Gerilim: 24 Volt
Boyut: 60x40 inç Tip: fotovoltaik
Güç Çıkışı: özelleştirilmiş Akım: 12,5 amper
İnvertör uyumluluğu: Mikro invertör, dizi invertör Sertifikalar: UL, CE, TUV
Malzeme: Silikon Hava Şartlarına Direnç: IP65
Garanti: 25 yıl Renk: mavi veya siyah

Solar module system module power panels for energy system



KUOMAN Solar Panel Details:



Solar module system module power panels for energy system 0Solar module system module power panels for energy system 1Solar module system module power panels for energy system 2Solar module system module power panels for energy system 3



Solar Panel Details Specification:
Commonly used module power(Wp)
280～470
Module compatibility
60-cell or72-cell PV modules
Peak power MPPT voltage range(V)
33～48
Start-up voltage(V)
22
Perating voltage range(V)
16～60
Maximum input voltage(V)
60
Maximum input current(A)
11.5
Maximum input short circuit current(A)
15
Output Data(AC)
Rated output power(VA)
350
Rated output current (A)
1.59/1.52/1.46
Nominal output voltage(V
220/230/240①
Nominal frequency(Hz)
50/60①
Displacement power factor
0.8 leading to 0.8lagging
Total harmonic distortion
<3%
Maximum units per branch(10AWG)
18/19/20
Efficiency
CEC peak efficiency
96.70%
CEC weighted efficiency
96.50%
Nomia MPPTefincy
99.80%
Nominal power consumption(mW)
< 50
Mechanical Data
Ambient temperature range(℃)
-40～+65
Dimensions(WxHxD mm)
184.5×204.5×26
Weight(kg)
1.7
Fnclosure rating
Outdoor-NEMA(IP 67)
Ccolng
Natural convection
Features
Communication
2.4G Hz Proprietary RF(Nordic)
Monitoring
Sofia Pro Cloud②
Compliance
VDE-R-N 4105:2018,EN 50549-1:2019,VFR 2019,
IEC/EN 62109-1/-2,IEC/EN 61000-6-1/-2/-3/-4.IEC/EN 61000-3-2/-3


Solar module system module power panels for energy system 4

Solar module system module power panels for energy system 5

Solar module system module power panels for energy system 6









Packing:
Normally packing: 1pc/2pcs/5pcs/10pcs/25pcs per carton/pallet
Individual packing requirement is acceptable.

Shipping:
Material in stock can be produced (procedure 5-20days) right away after pre-payment confirmation.
We will find the most suitable and safe mode of transportation,don't worry about package damage or loss. It takes about 7~15 working days to worldwide.
Please note us your contact details include your phone number for easy contacting from shipping company officer.

Shipping Methods
Arrive AT
Delivery From
By Sea
Sea Port Want
Any port in china
By Air
Specification
Any port in china
By Railway
Your door
Any railway station
By express
Specification
Zhengzhou City



KUOMAN Case:



Solar module system module power panels for energy system 7

Solar module system module power panels for energy system 8

Solar module system module power panels for energy system 9

Q1: How can I get your support?

A1: We have reliable forwarder agent which can ship items to you by sea/air/Express based on your situation. Anyway, we will help you choose the most suitable shipping service.



Q2:What's your shipping terms ?

A2:We can do FOB, CIF, EXW or DDP.



Q3: How is your technical support?

A3: We provide lifetime online guidence support through Whatsapp/ Skype/ Wechat/ Email

 Any problem afterdelivery, we will offer you video call anytime,our engineer will also go to oversea help our customersif necessary.



Q4: What's our payment ways?

A4:we generally using T/T, L/C payment ways.
